Prima Power - CP 4000 ZaphiroDE-LAS-PRI-2013-00001

Additional equipment

• Air dryer with filter
• Documentation (1 copy on CD)
• T eleservice module (incl. modem and installation)
• CAM MAESTRO Windows. Dongel license on the USB PORT / MAESTRO software package includes: - Nesting module
• .dwg Import / .dxf Multiimport - CycleTimeLight
• “Quick Piercing” oil spraying device
• Automatic pallet changer T yp P A
• Nozzle changer
• Scrap conveyor
• Extraction system (2. 400m3)

Machine Benefits

Qualitative Machine Benefits

• Collision protection device
• Capacitive sensor
• Warranty (4,000 hours / 24 months) (incl. Costs for teleservice)
• Safety cabin in accordance with ce/cdrh regulations
• Single user installation

Technical Machine Benefits

• F- axis: independent, programmable position of focus lens
• 5“; 7”; and 9” lens (thickness 9 mm) and cassette-type holder
• High pressure kit and gas selection (2 gases: nitrogen & oxygen)
• Work table with pallet and “fakir bed”
• Ethernet card in the control unit
• Cooling water preheating
• Machine defective nc encoder for y-axis (see screenshots from control).
